17 Diving Officer's Instrument Panel
Notice the numerals on the depth gage at the top of the photo are painted over. If the Albacore's Test Depth is 300' and the test depth is 1/3 the crush depth, then the gage would likely be graduated in 10' increments to 1,000', or 100' below crush depth.
