51 AIM-4A Falcon Missile

Hughes AIM-4 Falcon Air to Air Missile Specifications:

AIM-4 Falcon Air to Air Missiles at other aviation museums in the northeast
AIM-4 Falcon Air To Air Missile AIM-4 Falcon Air To Air Missile
AIM-4 Falcon Missile at the Delaware Valley Historical Aircraft Association Museum in Willow Grove, PA Another AIM-4 Falcon Missile at the Air Mobility Command Museum in Dover, DE
  AIM-4 Falcon Air To Air Missile
  One more AIM-4 Falcon Missile at the MAPS Air Museum in North Canton, OH

Length: 7 feet 2 inches
Wingspan: 2 feet, 0 inches
Diameter: 8 inches
Weight: 152 lbs
Max Speed: Mach 3
Range: 6.5 miles
Powerplant: Morton Thiokol M-46 solid fuel rocket motor
Guidance: Infared Heat Seeking
Warhead:
 High Explosive Fragmentation
First Flight : 1956
Cost: $386,000
